Move your Ag Data! AGBRIDGE and Ayrstone team up.

We are extremely excited to announce a new partnership with a new company and product that can revolutionize the way you work with the data from your operation.

AGBRIDGE has a simple device that connects to your in-cab computers and automatically uploads the data from those computers to their cloud service, where you can use it for your operations. It is an ingenious device that does some very simple but effective things:

  1. The AGBRIDGE Drive emulates a USB storage device – the USB “thumb drive” that the monitors were designed to use for data offload as well as uploading prescriptions and guidance files.
  2. It then can transmit the data from the monitor to their cloud service using WiFi or Cellular connection. It can use the WiFi from a cellular “hotspot,” including your cellphone’s hotspot capability, or it can send the data to your cellphone and then on to the AGBRIDGE cloud. But the best idea is to use your AyrMesh system to upload the data automatically without data limits.
  3. you can use it with a variety of software packages to analyze the results of your farm operations and plan next year. You can also view your data on your tablet or smartphone.

Our customers have high-speed outdoor WiFi because they either don’t have good cellular coverage or they sensibly don’t want to use their cellular connections and data allowances. We have been looking for a product like AGBRIDGE for a long time to help our customers collect the data off their devices automatically, and we are VERY excited to bring this to you. We worked with AGBRIDGE to create a very nice flyer to explain how AyrMesh and AGBRIDGE can work together to save you time and money while making you more effective on your farm. Please look at their website and get in touch with them

The Future is Coming – Get Ready for the Robots…

There is an image of farming – bucolic, peaceful, unfettered by the concerns of the technological age. It’s lovely, and many of us indulge it to some degree… but it is patently false. Agriculture is an industry moving quickly on the technology curve as markets demand more, higher-quality, and cheaper food and grains. Specialized implements, higher-horsepower machines, GPS steering, variable rate planting and spraying, and the cellphone have all had an impact on farm productivity. But that’s not all.

Waymo (Google) Self-Driving Car

Courtesy of Waymo

The Robots are coming.

Look, anybody who has sat in a tractor or combine moving through the field by itself using AutoSteer has to have thought, “Do I really need to be here?” In various cities around the U.S., we have been witness to Google vehicles (and others) happily (if sometimes slowly) wheeling themselves around town, their human handlers typing away on their laptops. If they can run sedans on public roads, they can run a tractor down a row of corn. There are a lot of questions about what the first (big) bunch of farm robots will be doing, but the Japanese have been using almost completely autonomous mini-tractors for rice transplanting for years. There are a lot of people and companies testing robots around the world for farming – big ones and little ones.

Case autonomous concept vehicle

Courtesy of CNH

We have been interested in robots on the farm because we had a vague sense they need a lot more data connectivity than is available in most places now. So I read this article with interest; to quote: “Internet access is a problem,” [Scott Shearer, professor and chair of Food, Agricultural and Biological Engineering, Ohio State University] said. “We need 10 megabits per second connection speed.” Data-gathering tools today can capture gigabytes of information that must be able to flow back to the driverless machine quickly and easily; and the machine must be able to communicate to a central location too.

In some places, cellular connectivity may be enough, but, as discussed earlier in this blog, we don’t expect cellular service to improve dramatically in rural America. And it’s going to still be expensive.

Our modest proposal: set up an AyrMesh network on your farm today for long-range WiFi. And be ready for the robots!

ClearPath robot

Courtesy of ClearPath Robotics



A Whole New Kind of AyrMesh Hub – the Hub2x2

The new AyrMesh Hub2x2

After extensive research, testing, and development, we are pleased to announce the all new AyrMesh Hub2x2.

The AyrMesh Hub2x2 is our first Hub to use MIMO to dramatically improve the upload and download speed, both between the Hub and your devices and between the meshed Hubs themselves. The Hub2x2 can deliver up to twice the data speed of the Hub2T, enabling our customers to do things like:

  • Use high-definition security cameras
  • Download manuals, diagrams, videos, etc. up to twice as fast
  • Make and Receive video calls
  • Stream HD movies – even out in the garden

MIMO is a technology that allows a WiFi access point (like the AyrMesh Hubs) to use multiple antennas that receive and transmit multiple “spatial streams” of data simultaneously. Multiple antennas also help make the signal more readily available in difficult places like in trees and around buildings.

The use of MIMO represents a new strategy for AyrMesh Hubs. Previous AyrMesh Hubs traded off bandwidth to achieve maximum range. The Hub2x2 combines outstanding bandwidth and excellent range to normal WIFI-enabled devices, with a small sacrifice in Hub-to-Hub range.

The reason for this tradeoff is that we have found that most of our customers have their Hubs within a mile of each other, and are primarily interested in ensuring good WiFi coverage with excellent speed around their home, pool, gardens, farm office, workshop, barns, chicken coops, and stables. The new Ayrmesh Hub2x2 is designed specifically for those needs while still enabling you to expand your AyrMesh network out into fields and across thousands of acres.

The Hub2x2 vs. the Hub2T

The AyrMesh Hub2x2 is a perfect Gateway Hub for almost any AyrMesh network, because it provides long range and high bandwidth. The Hub2x2 is also a great Remote Hub up to a mile away, making it an excellent product for providing high-bandwidth WiFi around a rural home, farm, or estate. By placing Hubs a mile or less apart, you can ensure a continuous “cloud” of WiFi for your devices.

For Remote Hub installations more than a mile away, we recommend using the Hub2T. Its single antenna “focuses” its signal much more for longer-range applications, which provides better bandwidth at those distances than the Hub2x2.

The only time we will recommend the Hub2T as a Gateway Hub is when a Remote Hub will be positioned over 2 miles away from the Gateway. In this case, the Hub2T will provide better bandwidth to the Remote Hub2T than the Hub2x2 would.

One other point: the Hub2T has MUCH lower power requirements than the Hub2x2, so it is more suitable for solar/wind powered installations.

The new AyrMesh Hub2x2 – a new kind of AyrMesh Hub

As always, please let us know what you think!



Introducing the New AyrMesh Receiver

We are pleased to introduce the new model of the AyrMesh Receiver. This new model represents a significant improvement on the older model while maintaining complete compatibility with previous AyrMesh products. This product combines the proven software from our previous model AyrMesh Receiver with new, more capable hardware. The new AyrMesh Receiver is a bit larger than the old model, and offers several new features:

  • Bigger, stronger antenna for more solid links
  • Mounting tabs on the back for mounting to poles or flat surfaces
  • “Extra” external Power-over-Ethernet (PoE) port on the Receiver for connecting external PoE devices like Cameras
  • Standard 48V power injector/power supply so standard 802.3af devices can use the external PoE port

The ability to mount the Receiver on a flat surface (without additional hardware) is a feature that many users requested over the years, and the ability to add an outdoor PoE device will, we think, enable our customers to enhance security and operational awareness.

Overall, the new Receiver represents a significant improvement over the old model. While the old models will continue to work perfectly, you might want to consider replacing an older Receiver with the new Receiver if:

  • It is in a marginal location, where it is just getting enough signal to make the link – the new Receiver’s more powerful antennas can help; or
  • You want to have an external PoE device – like an outdoor PoE IP camera, connected to the Receiver.

As always, we welcome your thoughts, questions, and comments.

Introducing the New AyrMesh Hub2T

AyrMesh Hub2TWe are pleased to announce the new AyrMesh® Hub2T.

The AyrMesh Hub2T is a direct replacement for the Hub2n, but with some important differences. It meshes with the Hub2n and any other AyrMesh “Hub2” products.

First off, the Hub2T is a lot bigger than the Hub2n, with a much bigger antenna and a tougher stainless steel mounting bracket. The bigger antenna improves the performance of the Hub, while the new bracket just makes the entire Hub more stable and reliable, whether it is mounted on a pole or a flat surface.

Paradoxically, the new Hub2T has a little less radio transmitting power (about half a watt vs. almost a watt for the Hub2n), but it performs better than the more powerful Hub2n. Why? That big antenna! Reducing the transmitting power allows us to use twice as powerful an antenna, and (at least to a degree) a higher-gain antenna is better than more transmitting power. Power allows the Hub to “shout” longer distances, but a higher-gain antenna enable the Hub to both “shout louder” and “listen better” – resulting in better overall performance.

The other interesting change is the addition of a “gland” on the bottom of the radio. This gland makes it a bit trickier to install the Hub, but it protects it from water splashing up from below. This addresses concerns we have heard from some livestock operators who want to put Hubs near livestock pens or in milking parlors or farrowing houses, but worry about having to spray water around the Hub. We still don’t recommend spraying water directly up at the Hub, but this Hub will better withstand inadvertent sprays of water from below.

The Hub2T also uses less power than the Hub2n, so it is better for solar-powered field installations – if you have experienced “dropouts” in winter due to low batteries on the solar system, the Hub2T will work better (although that may also be a sign you need to replace those batteries…)

Should you replace your Hub2n with a Hub2T? In most cases, no – you’re not going to see enough of a difference in performance to make it worthwhile. The only exception is where there is a danger of water splashing up from beneath the unit.

But, if you are just starting your AyrMesh network, and as you expand, the AyrMesh Hub2T will be a low-cost, no-hassle workhorse, whether it’s on a building or out in the field.

Quick Note: “5G” technology on the farm

I have a Google Alert for “Wireless Farm” – I get about an article a week (and many of them are about wireless technologies for “server farms” and other odd things). But today I got a link to this article about “How 5G will impact the future of farming.” Intrigued, I clicked it to find a puff-piece about how Deere wants better wireless connectivity so that combines can “talk” to each other via “the cloud,” pointing out that it can take up to a minute with current technology for one combine to upload its data to the cloud, then the other combine to download that data and act on it. A couple of points here:

  1. “5G” mobile technology is based on “millimeter-wave” bands – over 20 GHz. (20,000 MHz.). Current LTE is based on 700 MHz. radios, and previous mobile data technologies (2G/3G) were “piggybacked” on existing 800 MHz. and 1900 MHz. radios. The range and, in particular, the ability of a signal to penetrate solid objects varies inversely with the frequency. So, to have 5G covering the areas cellular covers today requires a MUCH higher density of cellular towers than we have; to have it cover all of the rural U.S. will require thousands and thousands of new towers, a huge infrastructure investment
  2. As I have mentioned previously, the vast majority of cellular infrastructure investment is happening (and will continue to happen) within cities and towns, where the density of opportunities for subscriber revenue makes it profitable.
  3. Within the article, however, is this paragraph:

The term “5G” refers to the fifth-generation wireless broadband technology based on the 802.11ac standard. The packet of technology will bring speed and coverage improvements from 4G, with low-latency wireless up to 1GB/s.

802.11ac is WiFi, not mobile (cellular) technology. Specifically, it is the current generation of WiFI using the 5.8 GHz. (5,800 MHz.) radio band.

And here’s the point: “5G” mobile technology is not going to have an impact on farm operations in the forseeable future. But you can have multi-megabit WiFi technology on your farm TODAY – and you don’t have to wait for your friendly cellular carrier to put up a zillion towers. FURTHERMORE, since your AyrMesh system puts all the devices onto YOUR OWN Local-Area Network (LAN), everything on the system can just talk to each other – they don’t have to upload to the cloud and download from the cloud or anything like that. Your combines can “talk” to each other and your trucks, you can automate processes and enable autonomous vehicles – NOW – with an AyrMesh WiFi network.



Privacy and Security on the Internet

On Monday, April 1, 2017, Congress passed and President Trump signed a bill to repeal rules that require ISPs to get your permission before selling information about your online habits. You can read more about it at USA Today or Ars Technica.

As soon as it was publicized, we received inquiries from Ayrstone customers about how they can protect themselves. Unfortunately, we really don’t have much we can offer. There is a lot of talk about Virtual Private Networks (VPNs), and some about the Tor Project, but neither is a very satisfactory solution.

VPNs securely route all your Internet traffic to the vendor’s routers, and then sends that traffic to the Internet. This will prevent your ISP from seeing your Internet habits (because, from their perspective, all your traffic is going to the VPN vendor), but clever spies can untangle your traffic from the VPN’s stream, and there is a danger that the VPN will simply collect your information and sell it.*

The Tor project is the result of a U.S. Navy project (paradoxically, while the government spends your money to reduce your privacy, they also have spent money to improve your privacy…). It is voluntary network of computers – you download their software, and all your traffic is routed through a seemingly random collection of computers around the globe before appearing again on the Internet from a random location. This is much more secure, but there are cases where agencies have re-assembled data from the Tor network.

Either VPNs or Tor will slow down your network, and neither offers perfect privacy. Various ISPs have vowed not to sell your internet usage data, and several states have started investigating passing local laws to protect privacy.

Add to this, unfortunately, that your ISP is far from the only source of information about your Internet usage. Google, Microsoft, Apple, and many, many others gather LOTS of information about your usage, and they use it to target advertising to you.

So there are three things you can do: first, use VPN or Tor software to increase your privacy, second, talk to your lawmakers about re-instating (and, preferably, increasing the scope of) the regulations around privacy, and, third, follow the advice of my old boss, Scott McNealy.


*There is another use of VPN – to connect a remote network to your LAN – and many of our customers use this kind of a VPN. In this case, you have a VPN router on your network, and you connect using VPN software or another VPN router to a remote network, such as (for example) a remote location where you have a different Internet “drop” from your home. In this use of a VPN, devices at that remote location get IP addresses and appear on the network as if they were in your home network, even though their traffic is routed out through a different Internet connection. This means you can be in the remote location and send a job to your printer at home, and it will be printed and ready when you get home, or you can access files on your home PC when you’re away. This does not help your privacy, except against information theft on public Internet connections, but it can make remote working more convenient.

The Internet of Things (IoT) on the Farm – Part 3

In Part 1 and Part 2 of this series, as well as the associated posts on the ezeio and sensor networks, I have focused primarily on IoT hardware: the part you can see and touch, and that touches your farm.

Firmware

However, in many ways, software is much more important than the hardware. As I observed in Part 2, modern technology products are remarkably similar: a CPU, some memory, some storage, and some peripherals. If the peripheral is a relay, you have a device that can turn things on and off (like a remote-controlled power plug, or a WebRelay). If the peripheral is an “Analog to Digital Converter” (ADC) then the device can monitor sensors and report the values from those sensors. Some devices like the ezeio have both (and even more).

Of course, nothing happens on these devices without software. And software is involved in at least two important places: the software that is running on the devices themselves, sometimes referred to as “firmware,” and the software running on back-end computers (local or cloud servers, PCs, or even your phone or tablet) that is used to store and interpret the results from the devices.

These two pieces of software have to be able to “talk” with each other, and we’ll assume* they do so over your network, with the device connected to your AyrMesh network and the “back-end” software on some sort of cloud-based server on the Internet. Note that the “back-end” software COULD reside on a server on your property if you are using AyrMesh.

What the devices themselves do depends on both the hardware and the firmware on the device – in most cases, that firmware will collect readings from the sensors, upload that information to the back-end server, and, if appropriate, take commands from that server and take action, from turning on a light to starting a pump or a grain auger.

In most cases, that firmware is a closed system – there is no way for you to collect data off or communicate with the device directly, or to direct it to a location other than the vendor’s cloud server. It doesn’t have to be that way, but (1) it’s simpler, and (2) that gives the vendor much more control over the data.

The back-end server usually stores the data and presents it to you (either through a web page or a mobile app, or both). What data you see, how you see it, and what you can do with it depends on that back-end software. It may just present a time series of observations in the field as a graph, it may let you set up simple or complex rules (if the soil moisture is at this level or below, turn on the irrigation system), and it be able to present data in many useful ways (different graphs, superimposed on maps, etc.) and enable very complex control of your farm machinery.

The back-end server is usually a closed system, as well – most times it can only accept data from the vendor’s own devices. Sometimes it may have an “Application Program Interface” (API) that allows it to exchange data with other programs. It may also have the ability to upload data into it for tracking and presentation, or to download data from it for importation into another program. These APIs and import/export mechanisms may be very good, well-written, and well-documented, making them extremely useful. Or they may not. APIs are generally only useful for programmers – it takes code to make them work – but well-written and well-documented APIs can enable even relatively inexperienced programmers to create custom programs to do exactly what you want, and that can be extremely valuable.

On the other hand, back-end software without good APIs and/or import/export features is a “closed box” – what you get is just what you get, and there’s no way to get more or less. Understand, of course, that a closed system like this may do EXACTLY what you need, but, if your needs change, it may suddenly become useless.

Of course, there is also the issue of your data and what happens to it. The terms and conditions for the service may be very clear about what happens to your data, or they may be quite vague. Many of the data services will anonymize and sell the data that you store on their servers (the most unethical may not even anonymize it – beware!). This may concern you or not, depending on the nature of the data and how closely tied to your operation it is. For instance, it is generally valuable to share weather data – if your neighbors do so as well, you can gain a much better insight into the local weather patterns. On the other hand, you may not want to share geo-referenced harvest data – that tells too many people exactly what your land and your harvest is worth. “Fuzzing up” the geo-reference, however, might make it a lot more shareable.

When you are considering new devices to collect data and/or control machinery on the farm, these distinctions between “open” and “closed” systems, and the availability if good, usable APIs may seem abstract. Salespeople for “closed” systems will do their best to minimize the importance of these issues, but it’s absolutely critical. Openness in the device’s firmware means that the devices can be re-purposed to work with another system if you don’t like the vendor’s services, and openness in the back-end database means you can easily get your data and move it where it can be combined with other data and used (e.g. providing it to your agronomist for analysis, or storing it in a system where it can be combined with other data for decision-making).

Being smart about buying new technology for your farm can save you a lot of money in the long term, and a lot of frustration in the short term. We’ll keep an eye out for and report on interesting products that help you on the farm using open technologies.

*some devices connect directly to the network using WiFi or Ethernet, and some devices will have low-power networking (e.g. Zigbee or Google Threads) that use a “gateway” device to connect them to your network (or directly to a public network via cellular or satellite). There are even some that don’t talk to the network at all, using either Bluetooth or an embedded WiFi server to communicate directly with your phone, tablet, or laptop. And, of course, there are still devices that use some sort of flash memory and “sneakernet” (taking the flash memory off the device and walking it to a computer).

Getting started with the IoT on the farm with ezeio



eze System

Courtesy of eze System

A few months ago, I was approached by the folks at eze System, who wanted to know if their ezeio product would work with AyrMesh to help farmers measure conditions on farms and control equipment.

ezeio-400px-300x239They were kind enough to send me one of the ezeio products so I could try it out. Insofar as it is a standard Ethernet (802.3) product, I had no doubt it would work perfectly with AyrMesh, and, of course, it did – I just connected it to an AyrMesh Receiver with an Ethernet cable and it appeared on my network.

What is cool about the ezeio is that it is a complete package – hardware, firmware, and back-end software – completely integrated and ready to plug in and go. It includes connection points for up to 4 analog inputs (configurable for 0-10V, 4-20mA current loop, S0-pulse, or simple on/off), Modbus devices, Microlan (1-wire) devices, and up to two relay outputs (up to 2 amps). This makes it a very versatile unit for both detecting and controlling things on the farm.

setup_smallI set mine up on a table to see how it worked. The good folks at eze System included a Microlan temperature probe, so I set up my unit with that connected to the Microlan connector and a couple of LEDs (with a battery) connected to one of the relay outputs.

loginI then went to their web-based dashboard and started setting things up. It’s pretty simple – you get a login on the dashboard, and you add your ezeio controller. You can then set up the inputs (in my case, the temperature probe) and outputs (the relay) and then set up rules to watch the inputs and take appropriate actions. If you want to see the details, I have put together a slide show for the curious so I don’t have to put it all here.

The bottom line is that I was able to quickly and easily set up a system that checked the temperature continuously and, when the temperature dropped below a certain level, lit up an LED. Big deal, I hear you say, BUT – it could easily have been starting a wind machine or an irrigation pump or some other machine, and it could have been triggered by a tank level switch or a soil moisture sensor or some other sensor or set of sensors. It also enables me to control those devices manually over the Internet, using a web browser, without having to “port forward” on my router.

The ezeio is a very powerful yet easy-to-use device which, in conjunction with the web service behind it, enables you to very easily set up monitoring and automation on your farm. For the do-it-yourselfer, it is a great way to get started on employing the Internet of Things (IoT) on your farm. Even if you’re not inclined to take this on yourself, any decent networking technician  can easily set up your AyrMesh network and the ezeio to help around the farm.

The Internet of Things (IoT) on the Farm – Part 2

arduinoIn Part 1, I talked a little bit about the vision for the internet of things, but I didn’t really define what I meant by the internet of things.

What I’m talking about when I talk about the Internet of Things is a profusion of small devices that are all connected to the network and therefore to the Internet. Whereas most of the things in your home that are connected to the network have keyboards and screens and are meant for you to interact with, I’m talking about things that instead have sensors and relays and actuators. In most cases, you won’t interact with them at all. They’ll just work automatically in the background either gathering data for you or controlling equipment. Most of these things you’ll set up and never touch them again, but they’ll be working quietly in the background for you day and night.

Ibm_pc_5150If you are as old as I am (and I hope you’re not!), you remember the first wave of personal computers: the Apple II, the CP/M machines like the Kaypro and Osborne, and the original IBM PC – these were amazing because they were real computers that could do useful things (spreadsheets, word processing, and calling bulletin board systems) but were small (the size of a suitcase, more or less) and inexpensive (a few thousand dollars – in the 1980s) enough for home use.

Raspberry Pi Zero - $5

Raspberry Pi Zero – $5

The kinds of computers that we are talking about here are significantly smaller (typically the size of a credit card) and significantly less expensive (most under $100, many of them less than $10), even though they have 10-100x the computing power of those early personal computers. Instead of keyboards and screens, they have network ports and connections for various sensors and/or actuators; most can run for hours or days on a small battery – some can run for months. They can sit in in a tiny place, collecting data and transmitting it to the network, or waiting for a command to do something, for years.

temp_sensor

Simple Air Temperature Sensor

Decagon Soil Sensor

Decagon Soil Sensor

There are also a wide variety of sensors available, from simple temperature or humidity sensors to weather sensors like anemometers and rain buckets to advanced soil sensors that can measure soil temperature, moisture, and electrical conductivity. There are even sensors for UV radiation, leaf wetness, and chemicals in air and water.

relay

Simple small relay

But these little devices can do more than just sit passively measuring conditions. Devices can also be connected to allow them to take action, from simply turning something on to controlling complex machinery automatically. For instance, it is fairly simple to use a simple, small relay to turn an electrical machine on or off.

Raven PWM Valve

Raven PWM Valve

Multiple relays can be used for multiple devices, and relays come from very small, low-power devices to very high-power solid-state relays for switching very heavy loads. Many of these computers, however, also have the ability to output Pulse-Width Modulated (PWM) signals to control variable-rate devices like valves (control pressure through a water valve for irrigation or a hydraulic valve for controlling machinery) and pumps.

75 Amp Solid-State Relay

75 Amp Solid-State Relay

What ties it all together, of course, is two things: a network and software (both on the device and acting as some sort of “back end” to store and manage the data coming from these devices). Without software, any computer, even a $5 one, is just dead weight; without a network, it’s just sitting out in the field collecting data it can’t move to someplace it can be useful.

We know how to build the network – what Ayrstone does is give you the ability to build a strong, standards-based wireless network across your farm – and in part 3 we’ll consider the software part.
